Communicating Via Modbus

The Sealevel SeaI/O series of digital I/O communicates serially using the Modbus protocol (http://www.modbus.org).

Enumerated below are the standard Modbus functions supported by the SeaI/O series of digital I/O. Following those are the Sealevel SeaI/O specific custom functions used for configuring and manipulating specific SeaI/O modules.

Standard Modbus Functions

(0x01) Read Coils


(0x02) Read Discrete Inputs


(0x03) Read Holding Registers


(0x04) Read Input Registers


(0x05) Write Single Coil


(0x06) Write Single Register


(0x0F) Write Multiple Coils


(0x10) Write Multiple Registers


Sealevel SeaI/O Specific Modbus Functions

(0x41) Read Programmable IO


(0x42) Write Programmable IO


(0x45) Get Module Configuration


(0x46) Set Software Slave ID


(0x47) Set Communications


(0x64) Set A/D & D/A Configuration


(0x65) Get A/D & D/A Configuration


(0x66) Get Extended Module Configuration
